Each of the below mentioned solvent / cleaner is specially
formulated to give the highest degree of cleanliness after
post solder cleaning
1000 SERIES SOLVENT
CLEANER
1000 series solvents are carefully controlled blend of highly
pure proprietary solvent and chemicals that is very effective
in flux residue removal.
1002 SOLVENT
CLEANER
This
solvent cleaner is a blend of pure polar and non-polar solvents,
designed for quick and efficient removal of rosin residues
and other organic contaminants, including ionic traces of
activating ingredients sometimes remaining after soldering.
It is meant for use in high-volume production to remove
flux residues from PCBs by ultrasonic as well as vapour
phase cleaning. It is also effective at room temperature
for ordinary immersion cleaning. It has excellent stability
and is considerably less toxic than most commercial solvent
cleaners. It has a large capacity for absorption of rosin.
Its rate of evaporation is comparatively low. It can be
reclaimed through distillation without undue loss of its
original properties.
1003
SOLVENT CLEANER
It is a specially stabilised halogenated hydro-carbon solvent.
Low toxicity, non-flammable, non-ionic and non-hygroscopic
characteristics are especially valuable in ultrasonic cleaning.
Compatibility with polymers especially poly carbonates should
be evaluated before application.
1050 BIO CLEANER
It is a bio-degradable aqueous saponifier type flux residue
remover. It is formulated as a concentrate for dilution
with water. It very efficiently and effectively removes
all rosin flux residue and water soluble flux residue. Being
alkaline in character it will neutralise organic and acid
base fluxes. It does not contain chlorinated solvents or
chlorides.
1076
SOLVENT CLEANER
It is a purified, low residue cleaner. It contains a complete
and perfected stabiliser system that is able to withstand
the stress of heat, oxygen, acidic and alkaline materials,
moisture, light and active metal chips, under the most rigorous
cold cleaning operations. It is a powerful and fast acting
solvent for removing rosin, oil, grease, tar, gum, wax,
and certain polymers and resins. It is ideal for cleaning
by cold flushing of critical heat sensitive electronic components.
1163
SOLVENT CLEANER
It is an environment friendly solvent designed as a direct
replacement for trichloroethane and HCFC. It is non-flammable
and can be used in most vapour degreasers and ultrasonic
cleaners. Its high solvency, low surface tension and out
standing penetration abilities enables it to clean the most
tightly packed assemblies. It is a one-stop solvent cleaning
system eliminating the need for rinsing and drying stages.
It does not corrode carbon steel, stainless steel, copper
& aluminium. It is compatible with epoxy resins, Mylar,
nylon, PVC, Teflon and HDPE.
|
1000 |
1002 |
1003 |
1050 |
1076 |
1163 |
|
Solvent cleaner |
Solvent cleaner |
Solvent cleaner |
Bio Cleaner |
Solvent cleaner |
Solvent cleaner |
|
Clear Liquid |
Clear Liquid |
Liquid |
Clear Liquid |
Clear Liquid |
Clear Liquid |
|
0.785@25°C |
1.41@25°C |
1.33@25°C |
0.985@25°C |
0.99@25°C |
1.25@25°C |
|
13°C(T.C.C) |
None |
None |
None |
Not Established |
None |
|
Water Clear |
Water Clear |
Water Clear |
Light Straw |
Water Clear |
Water Clear |
|
Alcoholic |
Characteristic |
Characteristic |
Characteristic |
None |
Sweet |
